QQE03-10
Pentode · IHT · B7G · 1955
“Push-pull beam in one envelope.”
Small-signal pentode for low-noise voltage amplification
Datasheet ↗SPICE
TRANSCONDUCTANCE0mA/V
Cgk0pF
Cgp0pF
Cpk0pF
GAIN0%
POWER13%
DRIVE50%
LINEARITY75%
EXECUTIVE SUMMARY
The QQE03-10 is a indirectly-heated pentode from Philips, introduced around 1955. Commonly used in transmitting applications. Push-pull beam in one envelope.
HISTORY
Introduced1955ManufacturerPhilipsEquivalentsNone
Golden AgeSPECIFICATIONS
Heater Voltage6.3V
Heater Current0.65A
Max Plate Voltage300V
Max Power5W
Sensitivity8 mA/V
Gain Factor—
Internal Impedance—
PinoutB7G
Era1955
RarityModerate
Input Capacitance8pF
Miller Capacitance0.1pF
Output Capacitance4pF
