AZ1 Rectifier Vacuum Tube

Rectifier4V / 1.1ASide Contact P8A

SourcePhilips AZ1 datasheetReviewed2026-05-29StatusDataModelCalcModelunder reviewPDF

Full-wave rectifier for vacuum tube power supply designs

Datasheet ↗

AZ1 — Philips·Telefunken — rectifier vacuum tube — (1935)

5.0pF

6.5pF

4.00pF

GAIN0%

POWER0%

DRIVE50%

LINEARITY75%

SPECIFICATIONS

Heater4 V · 1.1 A

Max Plate Voltage500 V

Pa max—

Gain Factor—

gm—

rp—

Inter-electrode capacitances

Cgk5 pF

Cgp6.5 pF

Cpk4 pF

PinoutSide Contact P8A

Era1935

RarityModerate

HEATER4V / 1.1A

MAX PLATE500V

BASEp8a

Source datasheets

8 manufacturer datasheets cross-checked for AZ1

8 verified

EXECUTIVE SUMMARY

The AZ1 is a directly-heated rectifier from Philips·Telefunken, introduced around 1935. Commonly used in rectifier applications. Classic European rectifier. Gentle delivery.

APPLICATIONS

Power supply rectification

Generic rectifier rectifier stage

HISTORY

Introduced1935ManufacturerPhilips·Telefunken

Pre-War

AZ1 Datasheet

Local mirror · PDF

↗

METRIX TESTER

Test this tube on a Metrix

SPICE model not yet available. Loadline calculator requires calibrated Koren parameters.
