6E6P
Pentode · IHT · 9-pin Noval · 1962
“Frame-grid tetrode. Long-life audiophile variant.”
Small-signal pentode for low-noise voltage amplification
TRANSCONDUCTANCE0mA/V
Cgk0pF
Cgp0pF
Cpk0pF
GAIN0%
POWER21%
DRIVE50%
LINEARITY75%
EXECUTIVE SUMMARY
The 6E6P is a indirectly-heated pentode from Reflector, introduced around 1962. Commonly used in driver / power applications. Frame-grid tetrode. Long-life audiophile variant.
VS 6E5P
Pd -1%Full comparison →
HISTORY
Introduced1962ManufacturerReflectorEquivalents6E5P
Late ProductionSPECIFICATIONS
Heater Voltage6.3V
Heater Current0.61A
Max Plate Voltage150V
Max Power8.25W
Sensitivity34 mA/V
Gain Factor—
Internal Impedance—
Pinout9-pin Noval
Era1962
RarityModerate
Input Capacitance6.5pF
Miller Capacitance0.1pF
Output Capacitance4pF
SPICE model not yet available. Loadline calculator requires calibrated Koren parameters.
