6360
Pentode · IHT · 12-pin Compactron · 1960
“Push-pull beam pentode.”
Small-signal pentode for low-noise voltage amplification
Datasheet ↗SPICE
TRANSCONDUCTANCE0mA/V
Cgk0pF
Cgp0pF
Cpk0pF
GAIN0%
POWER13%
DRIVE50%
LINEARITY75%
EXECUTIVE SUMMARY
The 6360 is a indirectly-heated pentode from RCA, introduced around 1960. Commonly used in push-pull applications. Push-pull beam pentode.
HISTORY
Introduced1960ManufacturerRCAEquivalentsNone
Late ProductionSPECIFICATIONS
Heater Voltage6.3V
Heater Current0.75A
Max Plate Voltage300V
Max Power5W
Sensitivity7 mA/V
Gain Factor—
Internal Impedance—
Pinout12-pin Compactron
Era1960
RarityModerate
Input Capacitance9pF
Miller Capacitance0.2pF
Output Capacitance4.5pF
